Features
DLC QPL v5.1 Listed
The DesignLights Consortium® (DLC) is a non-profit organization promotes high-quality, energy-efficient lighting products in collaboration with utilities and energy efficiency program members, manufacturers, lighting designers. DLC Listed high performing LED lighting products may qualify for rebates.
CCT and Lumen Selectable
Choose wattage/lumen output and color temperature before, during, or after the installation with integrated dip switch
Multisensor Control Option
Bi-Level Dimming control maximizes energy savings and is simpler than ever by combining an occupancy sensor, a timer, customizable three-step dimming switches and a photo sensor to detect the amount of ambient light surrounding the fixture.
Emergency Backup Available
When there is a power outage, the emergency backup driver and battery will power the
light for at least 90 mins.
NETWORKED LIGHTING CONTROL
OPTIONS AVAILABLE
Networked Lighting Controls (NLC) offer Luminaire Level Lighting Control (LLLC) based on Bluetooth-enabled Mesh Networking of Luminaires. Individual addressability enables luminaires to be communicated with each other within the zone/network. Luminaires can be grouped, trim and controlled by using the smart device app or connected wall switches. Scheduling, scene and sensors can be added for automation among the lights within the zone/group.
Specs & Variations
| Model | |||||||||
| Wattage Selectable | 40W | 30W | 25W | ||||||
| CCT Selectable | 3500K | 4000K | 5000K | 3500K | 4000K | 5000K | 3500K | 4000K | 5000K |
| FPNB/3-22D | 4,400 lm | 4,800 lm | 4,480 lm | 3,570 lm | 3,870 lm | 3,630 lm | 3,100 lm | 3,350 lm | 3,150 lm |
| Wattage Selectable | 50W | 40W | 30W | ||||||
| CCT Selectable | 3500K | 4000K | 5000K | 3500K | 4000K | 5000K | 3500K | 4000K | 5000K |
| FPNB/3-24D | 5,550 lm | 6,050 lm | 5,650 lm | 4,680 lm | 5,080 lm | 4,760 lm | 3,570 lm | 3,870 lm | 3,630 lm |
| Wattage Selectable | 40W | 30W | 25W | ||||||
| CCT Selectable | 3500K | 4000K | 5000K | 3500K | 4000K | 5000K | 3500K | 4000K | 5000K |
| FPNB/3-14D | 4,400 lm | 4,800 lm | 4,480 lm | 3,570 lm | 3,870 lm | 3,630 lm | 3,100 lm | 3,350 lm | 3,150 lm |
* all models are power and 3500k/4000k/5000k CCT field-adjustable.
Build Your Light
| Family | Model | Control | Emergency Backup | Optional Mounts |
FPNB/3 |  | | | |
22D - 2ft x 2ft, 40w/30w/25w Power & 3500/4000/5000k CCT adjustable | [blank] - None | [blank] - None | [blank] - None | |
24D - 2ft x 4ft, 50w/40w/30w Power & 3500/4000/5000k CCT adjustable | MC - PIR bi-level motion and daylight harvesting sensor | EM - Emergency backup | DG - Drywall flange | |
14D - 1ft x 4ft, 40w/30w/25w Power & 3500/4000/5000k CCT adjustable | WBP - Wireless bluetooth networked control w/PIR motion and daylight sensor (NLC) | SM - Surface mount |
* Ordering information is for reference only. Some product configurations are not available. Please consult spec sheets for specific product availability and for further details.
Documents & Downloads
  FPNB series (FPNB/3) Product Specification Sheet |
Previous Generations:
(2nd Generation)
FPNB series (2nd Gen, FPNB/2) Product Specification Sheet
(1st Generation)
FPNB series (1st Gen, FPNB) Product Specification Sheet
FPNB series (1st Gen, FPNB) Product Specification & Sales Sheet
* specifications are subject to change without notice.
FPNB series (FPNB/3) Installation Guide
Previous Generations:
(2nd Generation)
FPNB series (FPNB/2) Installation Guide
(1st Generation)
FPNB series Installation Guide
* installation instructions are subject to change without notice.
| wdt_ID | GENERATION | SKU | WATTAGE | CCT | IES File |
|---|---|---|---|---|---|
| 1 | 3rd (Latest) | FPNB/3-22D config. to 3500K 40W | 40 | 3500K | Download IES |
| 2 | 3rd (Latest) | FPNB/3-22D config. to 4000K 40W | 40 | 4000K | Download IES |
| 3 | 3rd (Latest) | FPNB/3-22D config. to 5000K 40W | 40 | 5000K | Download IES |
| 4 | 3rd (Latest) | FPNB/3-22D config. to 3500K 30W | 30 | 3500K | Download IES |
| 5 | 3rd (Latest) | FPNB/3-22D config. to 4000K 30W | 30 | 4000K | Download IES |
| 6 | 3rd (Latest) | FPNB/3-22D config. to 5000K 30W | 30 | 5000K | Download IES |
| 7 | 3rd (Latest) | FPNB/3-22D config. to 3500K 25W | 25 | 3500K | Download IES |
| 8 | 3rd (Latest) | FPNB/3-22D config. to 4000K 25W | 25 | 4000K | Download IES |
| 9 | 3rd (Latest) | FPNB/3-22D config. to 5000K 25W | 25 | 5000K | Download IES |
| 10 | 3rd (Latest) | FPNB/3-24D config. to 3500K 50W | 50 | 3500K | Download IES |
| GENERATION | SKU | WATTAGE | CCT | IES File |
| wdt_ID | QPL Model No. | Product ID | Version | Classification | Primary Use |
|---|---|---|---|---|---|
| 196 | FPNB/3-14D-8CT-(MC/EM/Blank/Both) | S-4LRAF3 | 5.1 | Standard | 1x4 Luminaires for Ambient Lighting of Interior Commercial Spaces |
| 197 | FPNB/3-24D-8CT-(MC/EM/Blank/Both) | S-I8NMA2 | 5.1 | Standard | 2x4 Luminaires for Ambient Lighting of Interior Commercial Spaces |
| 198 | FPNB/3-22D-8CT-(MC/EM/Blank/Both) | S-MIH8D2 | 5.1 | Standard | 2x2 Luminaires for Ambient Lighting of Interior Commercial Spaces |
| 199 | FPNB/2-22D-30/25/20-835-(EM or Blank)-(A6W+B4) | PPGGSG0M | 5.1 | Premium | 2x2 Luminaires for Ambient Lighting of Interior Commercial Spaces |
| 200 | FPNB/2-24D-40/35/30-835-(EM or Blank)-(A6W+B4) | PBDLIHO5 | 5.1 | Premium | 2x4 Luminaires for Ambient Lighting of Interior Commercial Spaces |
