Features
90+ CRI
90+ Color Rendering Index for accurate, vibrant color rendering in any environment.
White Color Switchable
Choose 5-color temperature (2700K/3000K/3500K/4000K/5000K) before, during or after the installation with integrated dip switch on the LED board.
Sensor and Emergency Option
An optional PIR motion sensor provides additional energy savings and convenience. Emergency Battery Backup option is also available.
New construction or Retrofit
Flush and surface-mount, designed for both new construction and retrofit applications.
Specs & Variations
| Model | Wattage | Lumen Package | 2700K | 3000K | 3500K | 4000K | 5000K |
|---|---|---|---|---|---|---|---|
| FSMD 4D10 | 10w | 600 lm | 591 lm | 607 lm | 618 lm | 625 lm | 611 lm |
| FSMD 6D15 | 15w | 1000 lm | 920 lm | 970 lm | 1,037 lm | 1,055 lm | 1,023 lm |
| FSMD 8D18 | 18w | 1,300 lm | 1,218 lm | 1,247 lm | 1,303 lm | 1,356 lm | 1,298 lm |
Build Your Light
| Family | Model | Color Temperature | Finish | Motion Sensor | Emergency Backup |
FSMD | ![]() | ![]() | ![]() | ![]() | ![]() |
4D10 - 4 inch lens / 10w | 5CCT - 90+ CRI, 2700K/3000K/3500K/4000K/5000K Switchable | WH - White (Standard) | (BLANK) - No motion sensor | (BLANK) - Non-EM backup | |
6D15 - 6 inch lens / 15w | MC - PIR Motion Sensor | EMJB - Junction Box EM | |||
8D18 - 8 inch lens / 18w | EMSM - Surface Mount EM |
* Ordering information is for reference only. Some product configurations are not available. Please consult spec sheets for specific product availability and for further details.
Documents & Downloads

FSMD series Product Specification Sheet
* specifications are subject to change without notice.
FSMD series Installation Guide
* installation instructions are subject to change without notice.
| wdt_ID | GENERATION | SKU | WATTAGE | CCT | IES File |
|---|---|---|---|---|---|
| 46 | 1st (Latest) | FSMD-4D10 2700K | 10 | 2700K | Download IES |
| 47 | 1st (Latest) | FSMD-4D10 3000K | 10 | 3000K | Download IES |
| 48 | 1st (Latest) | FSMD-4D10 3500K | 10 | 3500K | Download IES |
| 49 | 1st (Latest) | FSMD-4D10 4000K | 10 | 4000K | Download IES |
| 50 | 1st (Latest) | FSMD-4D10 5000K | 10 | 5000K | Download IES |
| 51 | 1st (Latest) | FSMD-6D15 2700K | 15 | 2700K | Download IES |
| 52 | 1st (Latest) | FSMD-6D15 3000K | 15 | 3000K | Download IES |
| 53 | 1st (Latest) | FSMD-6D15 3500K | 15 | 3500K | Download IES |
| 54 | 1st (Latest) | FSMD-6D15 4000K | 15 | 4000K | Download IES |
| 55 | 1st (Latest) | FSMD-6D15 5000K | 15 | 5000K | Download IES |
| GENERATION | SKU | WATTAGE | CCT | IES File |
*IES files might not cover all options
